| Refitted Vehicle Main Technical Specifications | ||||
| Vehicle Model: | XKC5031XLC6F | |||
| Vehicle Type | Mini Truck | |||
| Vehicle Manufacturer | AVIC Henan Xinfei Special Purpose Vehicle Co., Ltd. | |||
| Vehicle Brand | AVIC XINFEI | |||
| Vehicle Overall Size (LxWxH) | mm | 4760 | 1610 | 2470/2260 |
| Box Internal Size (LxWxH) | mm | 2640/2500 | 1490 | 1550/1340 |
| Box Volume | m³ | 5.0~6.1 | ||
| Panel Thickness | mm | 55~120 | ||
| Interior/Outer FRP Lining | Food Grade, Light White | |||
| Insulation Material | PU | |||
| Insulation Material Density | 40kg/m³ (bottom panel), 35kg/m³ (other panels) | |||
| Thermal Conductivity | W/m.K | 0.023 | ||
| GVW | kg | 2840 | ||
| Curb Weight | kg | 1430 | ||
| Payload Weight | kg | 1280 | ||
| Fuel Consumption | l/100km | 7.5 | ||
| Maximum Speed | km/h | 100 | ||
| Rated Cab Passengers | person | 2 | ||
| Front/Rear Suspension | mm | 720/1340 | ||
| Approach/Departure Angle | ◦ | 40/25 | ||
| Chassis Manufacturer | CHONGQING CHANG'AN | |||
| Chassis Model | SC1031XND6B1 | |||
| Transmission Type | Manual | |||
| Engine Manufatcurer | Ha'erbin Dongan / Chongqing Yu'an / Chongqing Yu'an / Liuzhou Wuling | |||
| Engine Model | DM16KR / DK12C / SFG16C / LJ169Q-AEB | |||
| Engine Power | 90kW / 67kW / 90kW / 67kW | |||
| Fuel Type | Gasoline | |||
| Emissoin Standard | China VI | |||
| Steering Type | LHD or RHD | |||
| Tyre Specification | 165R14LT8PR, 175R14LT8PR | |||
| Tyre QTY | 4 pcs | |||
| Antilock Brake System (ABS) | YES | |||
| Rear Door - standard | Rear Swing Dual Doors | |||
| Options: | 1. Checkered aluminum flooring & skirt plates; | |||
| 2. Aluminum T-flooring & checkered aluminum skirt plates; | ||||
| 3. Side single door and/or dual doors; | ||||
| 4. Cargo side track, rails, shelves; | ||||
| 5. Aluminum-alloy meat hanging tracks & 304# stainless steel hooks; | ||||
| 6. Thermo King, Carrier, AVIC Xinfei, Yuhwa Thermo brands TR units. | ||||
| 7. Others. | ||||
