Refrigerated Vehicles

XKC5032XLC6B

A chassis cab truck is a commercial vehicle, and it's more basic than the pickup, with fewer features available. Its capabilities are designed for function, especially transporting heavy materials. The front looks about the same as the pickup, but the rear has a reinforced platform instead of a boxed pickup bed.

Overall Size:

12x2.5x2.85 m

Body Internal:

9.6x2.35x2.55 m

Engine Power:

150 kW

Emmssion:

China VI

Inquiry

Advisory

Features

Responsible for Yan Xing

This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,

Responsible for Yan Xing

This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,

Responsible for Yan Xing

This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,

Responsible for Yan Xing

This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,

Calm operation adds points for convenience

Cutaway van chassis are similar vehicles, but have specific components at the rear whereas chassis cabs usually do not have additional components.

Product Specifications

Refitted Vehicle Main Technical Specifications
Vehicle Model:		XKC5032XLC6B
Vehicle Type		Mini Truck
Vehicle Manufacturer		AVIC Henan Xinfei Special Purpose Vehicle Co., Ltd.
Vehicle Brand		AVIC XINFEI
Vehicle Overall Size (LxWxH)	mm	5670/5270	1860	2700
Box Internal Size (LxWxH)	mm	3750/3350	1710	1700
Box Volume	m³	9.74~10.9
Panel Thickness	mm	55~120
Interior/Outer FRP Lining		Food Grade, Light White
Insulation Material		PU
Insulation Material Density		40kg/m³ (bottom panel), 35kg/m³ (other panels)
Thermal Conductivity	W/m.K	0.023
GVW	kg	3495
Curb Weight	kg	2370/2150
Payload Weight	kg	995/1215
Fuel Consumption	l/100km	9.8
Maximum Speed	km/h	100
Rated Cab Passengers	person	2
Front/Rear Suspension	mm	1075/1395, 1075/1345
Approach/Departure Angle	◦	23/24, 23/18
Chassis Manufacturer		FOTON
Chassis Model		BJ1032V5JV5-01
Transmission Type		Manual
Engine Manufatcurer		Ha'erbin Dong'an / Ha'erbin Dong'an
Engine Model		DAM15KL / DAM16KL
Engine Power		85kW / 90kW
Fuel Type		Gasoline
Emissoin Standard		China VI
Steering Type		LHD or RHD
Tyre Specification		185R14LT6PR, 175R14LT-8PR
Tyre QTY		6 pcs
Antilock Brake System (ABS)		YES
Rear Door - standard		Rear Swing Dual Doors
Options:		1. Checkered aluminum flooring & skirt plates;
		2. Aluminum T-flooring & checkered aluminum skirt plates;
		3. Side single door and/or dual doors;
		4. Cargo side track, rails, shelves;
		5. Aluminum-alloy meat hanging tracks & 304# stainless steel hooks;
		6. Thermo King, Carrier, AVIC Xinfei, Yuhwa Thermo brands TR units.
		7. Others.
