Refrigerated Vehicles


XKC5040XLC6Q
A chassis cab truck is a commercial vehicle, and it's more basic than the pickup, with fewer features available. Its capabilities are designed for function, especially transporting heavy materials. The front looks about the same as the pickup, but the rear has a reinforced platform instead of a boxed pickup bed.
XKC5040XLC6Q
Features
Product Specifications
ONLINE SERVICE
Features
1
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
2
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
3
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
4
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
Calm operation adds points for convenience
Cutaway van chassis are similar vehicles, but have specific components at the rear whereas chassis cabs usually do not have additional components.
Product Specifications
Refitted Vehicle Main Technical Specifications
Vehicle Model: XKC5020XLC6B
Vehicle Type Light Truck
Vehicle Manufacturer AVIC Henan Xinfei Special Purpose Vehicle Co., Ltd.
Vehicle Brand AVIC XINFEI
Vehicle Overall Size  (LxWxH) mm 5230/4980 1790/1720 2640/2580
Box Internal Size  (LxWxH) mm 3050/2840 1640/1610 1700/1720/1600
Box Volume 32.5
Panel Thickness mm 80~120
Interior/Outer FRP Lining   Food Grade, Light White
Insulation Material/Density   PU
Thermal Conductivity  W/m.K 0.025
GVW kg 2200
Curb Weight kg 1640
Payload Weight kg 430
Fuel Consumption l/100km 8
Maximum Speed km/h 100
Rated Cab Passengers person 2
Front/Rear Suspension mm 605/1455, 605/1305
Approach/Departure Angle 34/25
Chassis Manufacturer FAW
Chassis Model BJ1020V3JV5-02
Transmission Type Manual
Engine Manufatcurer WEICHAI
Engine Model
Engine Power 180 hp
Fuel Type Diesel
Emissoin Standard China VI
Steering Type LHD or RHD
Tyre Specification
Antilock Brake System (ABS) YES
Rear Door - standard Rear Swing Dual Doors
Options: 1. Checkered aluminum flooring & skirt plates;
2. Aluminum T-flooring & checkered aluminum skirt plates;
3. Side single door and/or dual doors;
4. Cargo side track, rails, shelves;
5. Aluminum-alloy meat hanging tracks & 304# stainless steel hooks;
6. Thermo King, Carrier, AVIC Xinfei, Yuhwa Thermo brands TR units.
7. Others.
