| Refitted Vehicle Main Technical Specifications | ||||
| Vehicle Model: | XKC5181XLC6B | |||
| Vehicle Type | Refrigerated Vehicle - Midi Truck | |||
| Vehicle Manufacturer | AVIC Henan Xinfei Special Purpose Vehicle Co., Ltd. | |||
| Vehicle Brand | AVIC XINFEI | |||
| Vehicle Overall Size (LxWxH) | mm | 10220/10070 | 2600 | 3800 |
| Box Internal Size (LxWxH) | mm | 7800/7610 | 2400 | 2400 |
| Box Volume | m³ | 43.8~45 | ||
| Panel Thickness | mm | 55~120 | ||
| Interior/Outer FRP Lining | Food Grade, Light White | |||
| Insulation Material | PU | |||
| Insulation Material Density | 40kg/m³ (bottom panel), 35kg/m³ (other panels) | |||
| Thermal Conductivity | W/m.K | 0.023 | ||
| GVW | kg | 18000 | ||
| Curb Weight | kg | 7620/7400 | ||
| Payload Weight | kg | 10250/10185/10470/10405 | ||
| Fuel Consumption | l/100km | 23.1/23.6 | ||
| Maximum Speed | km/h | 105/89 | ||
| Rated Cab Passengers | person | 2,3 | ||
| Front/Rear Suspension | mm | 1270/3200, 1270/3050 | ||
| Approach/Departure Angle | ◦ | 21/8 | ||
| Chassis Manufacturer | FOTON | |||
| Chassis Model | BJ5186XXY-1A | |||
| Transmission Type | Manual | |||
| Engine Manufatcurer | F-Cummins/F-Cummins/F-Cummins/D-Cummins/D-Cummins | |||
| Engine Model | F3.8NS6B190/F4.5NS6B220/F4.5NS6B190/B6.2NS6B230/B6.2NS6B245 | |||
| Engine Power | 140/162/140/169/177 kW | |||
| Fuel Type | Diesel | |||
| Emissoin Standard | China VI | |||
| Steering Type | LHD or RHD | |||
| Tyre Specification | 10.00R20-18PR, 11R22.5-18PR, 275/80R22.5-18PR | |||
| Tyre QTY | 6 pcs | |||
| Antilock Brake System (ABS) | YES | |||
| Rear Door - standard | Rear Swing Dual Doors | |||
| Options: | 1. Checkered aluminum flooring & skirt plates; | |||
| 2. Aluminum T-flooring & checkered aluminum skirt plates; | ||||
| 3. Side single door and/or dual doors; | ||||
| 4. Cargo side track, rails, shelves; | ||||
| 5. Aluminum-alloy meat hanging tracks & 304# stainless steel hooks; | ||||
| 6. Thermo King, Carrier, AVIC Xinfei, Yuhwa Thermo brands TR units. | ||||
| 7. Others. | ||||
